Force Sensor

HH8204A08

Product description: Miniature weighing sensor
INQUIRY

Features＆Applications
Small size HH8204A08
Small deformation,low height
High quality stainless steel
Easy to install,fast
Surface electrolytic corrosion protection
Suitadle for linited space automation equipment
force detection and control of small devices
Capacity:5KG 10KG 20KG 30KG 50KG

Product Size:

Force direction:

Specification:
Rated Output:1.0±0.2mv/v
Total Accuracy:≤1%of rated output
Excitation:5~8V DC/AC
Zero Balance:±2% of rated output
Nonlinearity:±1% of rated output
Hysterrsis:±1% of rated output
Repeatability:±1% of rated output
Creep(30min):±1% of rated output
Safe Overload:120%
Ultimate Overload:150%
Compensated Temp.range:-5℃to+40℃
Operating Temp.range:-5℃to+40℃
Temp.Shifr Zero:≤0.05% of rated output/℃
Temp.Shift Span:≤0.05% of rated output/℃
Input Resistance:1000Ω+100Ω
Output Resistance:1000Ω+100Ω
Insulation Resistance:≥5000MΩ(100V DC)
Ingress Protection:IP65
Cable Color:Red(E+) Black(E-) Green(S+) White(S-)

Schematic:
