HH802

HH802 weight amplifier

The main application and PLC microcomputer automatic programming, stable quality and reliable quality

Two - stage dual stabilized electronic filters are added to ensure power supply interference in harsh environments

Power supply: AC12V~24V DC16V~30V

AD sampling rate: 40SPS

Output range: 0~5v 0~10v 4~20MA(specifications optional)

Comprehensive accuracy: better than 0.05%

Resolution: 16 bits

Power consumption: 25ma@1 350 ohm sensor

Output linearity: better than 0.02% (0.1%)

Shell material: aluminum alloy

Enclosure protection grade: IP64

Dimensions:
